Concrete Batching Plant

Concrete batching plant is mainly composed of five systems including the material storage system, the material weighting system, the material transporting system, control system, main mixer, and other auxiliary facilities. It is widely used for building construction like bridge, house construction, ground beam construction, etc. Our products have exported many countries and regions from all over the world. In addition, we have our own factories and offices in many countries. We offer excellent service and high quality structures. Welcome to visit us.

AJ-25
ModelAJ-25
Theoretical Productivity (m³/h)25
Mixer Model (Mixer Output L)JS500
Mixer Power (kW)18.5
Mixing Cycle Period (s)67
Rated Input Volume (Model of Batching Machine L)800
Max.Aggregate Size (mm)Φ60
Max. Discharging Height (m)3.8
Overall Weight (ton)≈15
Installation Power (kW)≈65
AJ-35
ModelAJ-35
Theoretical Productivity (m³/h)35
Mixer Model (Mixer Output L)JS750
Mixer Power (kW)30
Mixing Cycle Period (s)72
Rated Input Volume (Model of Batching Machine L)1200
Max.Aggregate Size (mm)Φ60
Max. Discharging Height (m)4.1
Overall Weight (ton)≈18
Installation Power (kW)≈75

Concrete Plant Specifications: Please click below and learn more.


Stationary concrete plant parameters

Model Bucket type Belt type
AJ-25 AJ-35 AJ-50 AJ-75 AJ-60 AJ-90 AJ-120 AJ-180
Theoretical Productivity (m³/h) 25 35 50 75 75 90 120 180
Mixer Model (Mixer Output L) JS500 JS750 JS1000 JS1500 JS1000 JS1500 MAO3000/2000 (SICOMA) MAO4500/3000 (SICOMA)
Mixer Power (kW) 18.5 30 2×18.5 2×30 2×18.5 2×30 2×37 2×55
Mixing Cycle Period (s) 67 72 72 72 60 60 65 65
Rated Input Volume (Model of Batching Machine L) 800 1200 1600 2400 1600 2400 3000 4500
Max.Aggregate Size (mm) Φ60 Φ60 Φ60 Φ80 Φ60 Φ80 Φ80 Φ80
Standard Aggregate Bin Capacity (m³) 3×3 3×5 3×8 3×12 4×7 4×15 4×15 4×20
Category of Aggregate 2/3 2/3/4 3/4 3/4 4/5 4/5 4/5/6 4/5/6
Powder Storage Silo (ton) (Optional) 1×50 2×50 1×100 2×100 2×100 3×100 4×200 4×200
Max. Discharging Height (m) 3.8 4.1 4.1 4.1 4.1 4.1 4.3 4.3
Weighing Range & Accuracy of Aggregate (kg) (300~1000) ±2% (300~1000) ±2% (300~1000) ±2% (300~1500) ±2% (300~1000) ±2% (300~1500) ±2% (300~2000) ±2% (300~3000) ±2%
Weighing Range & Accuracy of Cement (kg) (100~300) ±1% (100~300) ±1% (100~750) ±1% (100~900) ±1% (100~750) ±1% (100~900) ±1% (100~1200) ±1% (100~1800) ±1%
Weighing Range & Accuracy of Water (kg) (60~150) ±1% (60~150) ±1% (100~300) ±1% (100~400) ±1% (100~300) ±1% (100~400) ±1% (100~600) ±1% (100~800) ±1%
Weighing Range & Accuracy of Additive (kg) (5~20) ±1% (5~20) ±1% (5~20) ±1% (5~25) ±1% (5~20) ±1% (5~25) ±1% (5~30) ±1% (5~50) ±1%
Overall Weight (ton) ≈15 ≈18 ≈23 ≈30 ≈40 ≈68 ≈93 ≈101
Installation Power (kW) ≈65 ≈75 ≈100 ≈140 ≈110 ≈160 ≈220 ≈290
Power Supply

380V/220V/415/440V, 50/60HZ, 3Phase


Mobile concrete plant parameters

Model Belt Type
AJY-25 AJY-35 AJY-50
Theoretical Productivity (m³/h) 25 35 50
Mixer Model (Mixer Output L) JS500 JS750 JS1000
Mixer Power (kW) 18.5 30 2×18.5
Mixing Cycle Period (s) 67 72 72
Rated Input Volume (Model of Batching Machine L) 800 1200 1600
Max.Aggregate Size (mm) Φ60 Φ60 Φ60
Standard Aggregate Bin Capacity (m³) 2×3 2×5 3×5
Category of Aggregate 2/3/4
Powder Storage Silo (ton) (Optional) 1×50 2×50 1×100
Max. Discharging Height (m) 3.8 3.8 4.1
Weighing Range & Accuracy of Aggregate (kg) (300~1500)±2% (300~1500)±2% (300~3000)±2%
Weighing Range & Accuracy of Cement (kg) (100~300)±1% (100~300)±1% (250~900)±1%
Weighing Range & Accuracy of Water (kg) (60~150) ±1% (60~150) ±1% 80~300)±1%
Weighing Range & Accuracy of Additive (kg) / (8~20) ±1% (8~20) ±1%
Overall Weight (ton) ≈15 ≈22 ≈26
Installation Power (kW) ≈61 ≈73 ≈92
Power Supply 380V/220V/415/440V, 50/60HZ, 3Phase


Concrete Batching Plant Applications

The concrete mixing station is a combined device for concentrated mixing of concrete, which is also known as precast concrete filed. Because of its high degree of mechanization and automation, it has high productivity. In addition, it can guarantee the quality of concrete and save cement. It is often used in large and medium-sized water conservancy, electric power, bridges and other projects with large amount of concrete engineering, long construction period and concentrated construction sites. With the development of municipal construction, the batching plant which is used concentrated mixing and providing commercial concrete has great advantages. So, it has been rapidly developed, and it creates conditions for the promotion of concrete pumping construction and the joint operation of mixing, transporting and pouring machinery.

AJ-60
ModelAJ-60
Theoretical Productivity (m³/h)60
Mixer Model (Mixer Output L)JS1000
Mixer Power (kW)2×18.5
Mixing Cycle Period (s)60
Rated Input Volume (Model of Batching Machine L)1600
Max.Aggregate Size (mm)Φ60
Max. Discharging Height (m)4.1
Overall Weight (ton)≈40
Installation Power (kW)≈110
AJ-50
ModelAJ-50
Theoretical Productivity (m³/h)50
Mixer Model (Mixer Output L)JS1000
Mixer Power (kW)2×18.5
Mixing Cycle Period (s)72
Rated Input Volume (Model of Batching Machine L)1600
Max.Aggregate Size (mm)Φ60
Max. Discharging Height (m)4.1
Overall Weight (ton)≈23
Installation Power (kW)≈100

Various Types of Concrete Batching Plant from China

In general, according to different types, we have different classifications.

  1. According to different models, it is divided into stationary and mobile batching plants.
  2. According to the usage, it can be divided into commercial concrete mixing plant and engineering concrete mixing plant.
  3. According to different applications, it can be divided into dry mix concrete batching plant and wet mix concrete batch plant.
  4. According to weighting system method, it can be divided into independent weighting and cumulative weighting concrete batch plant.
  5. According to the production rate, it can be divided into mini type, small type, and large concrete mixing plant.
AJ-75
ModelAJ-75
Theoretical Productivity (m³/h)75
Mixer Model (Mixer Output L)JS1500
Mixer Power (kW)2×30
Mixing Cycle Period (s)72
Rated Input Volume (Model of Batching Machine L)2400
Max.Aggregate Size (mm)Φ80
Max. Discharging Height (m)4.1
Overall Weight (ton)≈30
Installation Power (kW)≈140

AJ-90
ModelAJ-90
Theoretical Productivity (m³/h)90
Mixer Model (Mixer Output L)JS1500
Mixer Power (kW)2×30
Mixing Cycle Period (s)60
Rated Input Volume (Model of Batching Machine L)2400
Max.Aggregate Size (mm)Φ80
Max. Discharging Height (m)4.1
Overall Weight (ton)≈68
Installation Power (kW)≈160

Of course, according to different functions and applications, it also has many other classification standards. For example, according to the feeding methods, it can be divided into belt type concrete batching plant and hopper loading concrete batch plant in our company. In conclusion, if you choose our products, you can get the customized and standard concrete mixing plant for your business.

Mobile Concrete Batching Plant

Generally speaking, mobile concrete plant type is very popular in work usage. Mobile plant has many operation systems including the material storage, weighting, transporting, mixing, unloading and full automatic control system. In fact, the mobile type operation is the same with stationary automatic concrete batch plant type in aspect of the movement process, operation method, maintenance and repair model. In addition, it has many advantages with flexible movement, quick and easy installation and assembly, simple storage and management. It is widely used in many construction places like public railway, bridge, port, electric power and other projects. For some special places, the mobile concrete batch plant it is the best matching machine. If you have needs, please get in touch with us as soon as possible.

AJY-25
ModelAJY-25
Theoretical Productivity (m³/h)25
Mixer Model (Mixer Output L)JS500
Mixer Power (kW)18.5
Mixing Cycle Period (s)67
Rated Input Volume (Model of Batching Machine L)800
Max.Aggregate Size (mm)Φ60
Max. Discharging Height (m)3.8
Overall Weight (ton)≈15
Installation Power (kW)≈61
AJY-35
ModelAJY-35
Theoretical Productivity (m³/h)35
Mixer Model (Mixer Output L)JS750
Mixer Power (kW)30
Mixing Cycle Period (s)72
Rated Input Volume (Model of Batching Machine L)1200
Max.Aggregate Size (mm)Φ60
Max. Discharging Height (m)3.8
Overall Weight (ton)≈22
Installation Power (kW)≈73

Stationary Concrete Batching Plant

In our company, if you choose the stationary concrete plant, we will introduce the high quality type and is called AJ-25-240. it is a complete set of equipment and concept choice for the production of commercial concrete. It is widely used in the large and medium-sized construction projects, bridge, road, precast concrete plants, etc. Generally speaking, we adopt the computer control system and it is convenient for operators to use. Of course, it has many advantages with compact structure, reliable performance, simple operation, etc. It has two feeding methods with hopper type and belt type concrete mixing plant, which can meet different needs of customers.

AJ-180
AJ-240

Many Advantages of Concrete Batching Plant for Sale

  1. It has compact structure and reliable performance. The machine adopts advanced technology to design every product part and ensure the safety and reliability.
  2. It has simple operation. The control system adopts the automatic control equipment. So, the users can be easy to operate the entire system.
  3. It has wide applications and many functions. It can work in many construction places like, road, bridge engineering, long term building places, etc.
  4. It has friendly environmental protection. The concrete plant install the equipment and release pollution water and others.
  5. It has long service life. It adopts the advanced technology to improve the traditional structure. The machine has compact structure and long service life.
  6. We have professional after sales service. In order to ensure customers’ requirements, we employee many professional staff including experts and some famous engineers who help the customers deal with various problems in our company.
AJY-50
ModelAJY-50
Theoretical Productivity (m³/h)50
Mixer Model (Mixer Output L)JS1000
Mixer Power (kW)2×18.5
Mixing Cycle Period (s)72
Rated Input Volume (Model of Batching Machine L)1600
Max.Aggregate Size (mm)Φ60
Max. Discharging Height (m)4.1
Overall Weight (ton)≈26
Installation Power (kW)≈92
AJ-50
ModelAJ-50
Theoretical Productivity (m³/h)50
Mixer Model (Mixer Output L)JS1000
Mixer Power (kW)2×18.5
Mixing Cycle Period (s)72
Rated Input Volume (Model of Batching Machine L)1600
Max.Aggregate Size (mm)Φ60
Max. Discharging Height (m)4.1
Overall Weight (ton)≈23
Installation Power (kW)≈100

Concrete Batching Plant Manufacturers and Suppliers

As the reliable concrete batch plant manufacturer and supplier in China, we have the high reputation from all over the world. In addition, we have professional after sales service team. If you choose our high quality products, we can give the free guidance for installation the plant. In addition, according to requirements, we can offer the professional technology guidance and good operation method. As for long as, we pay attention to research and develop about each system part. We hope the customers have the safe and reliable production line when you work. This is our responsibility that make the customers satisfaction and get the reliable concrete plant. If you want to get  the professional concrete mixing plant from standard manufactures and suppliers, please get in touch with us as soon as possible. We will give the reasonable price for our own clients.

AJY-60
AJY-75

Concrete Batching Plant Cost

We have a series of devices to offer our own customers. According to the demands and sizes, or other some factors, the customers have different choices for these machines. We pay more attention the plant value for daily operation. Of course, some customers have special needs. For example, they want to customize the machine. Or some want to non standard design. In addition, your products are used in harsh environments. In conclusion, we can meet your needs. of course, we adopt the standard materials and design to manufacture the excellent products. If you want to learn detail batching plant price, please consult our staff. They have the professional information to offer you.

concrete mixer
cement silo

Concrete Batching Plant for Sale

With development of technology and construction industry, people have the high demands about concrete plant. On the one hand, it can reduce cost for man power labor and save more time, because the construction industry needs large source and long work time, which improves the work efficiency and reduces the work time. On the other hand, it has advanced development tendency and is suitable for many countries’ production equipment. If you want to get these devices from professional batching plant manufacture, please contact us as soon as possible. If you have time, please visit our factory in China and you will find out more surprises.

Cases

Uzbekistan Installation
Tajik AJ-50 Installation
Philippines-AJ-35 Installation
